CSF 2019+ Lamborghini Urus / 2020+ Audi RS Q8 / SQ8 / SQ7 High Performance Intercooler System- Black

Ships In: 3-5 days

Year Range: 2019/2020-Present

Product Details

CSF High-Performance Intercooler System for Urus / RS Q8 / Cayenne 4.0L Turbo Features ( CSF #8211 / #8211R ):

• Sold as a pair (Left & Right Intercoolers)
• Eliminates Heat Soak and Lower Intake Air Temperatures (IAT) for Maximum Performance in High-Performance and Race Conditions
• Formula-1 Performance Grade Cores by PWR (2-Row Cores features Rolled Tubes w/ Inner Fins)
• CNC Machined Billet End Tanks
• 100% TIG Welded vs OEM Crimped Plastic End Tanks for Maximum Strength & Durability
• Made in the USA at PWR North America
• Integrated 1/8th NPT Port with plug on lower outlet tank for Water-Methanol Injection
• OEM Style Inlet/Outlet Connections for Precise Fitment With All OEM Components
• Finished in CSF’s Thermal Dispersion Cerakote(CSF #8211)
• Raw Finish with no coating for the “show” look or custom finishes available upon request (CSF #8211R)
• True Plug-and-Play “Drop-in Fit” Installation Requires Absolutely No Modifications
• R&D and Performance Testing by Pacific German & VF Engineering
• 1-Piece Welded Charge Pipe vs OEM Bolt-On Pipe w/ O-Ring (known failure point)

• Performance Gains:
  • Stage 1 (Stock Tune) – Approx. +20 WHP / +18 WTQ*
  • Stage 2 (With High-Performance Tune) – Approx. +10 WHP / + 20 WTQ*
    _{*Estimated Performance based on same engine platform Audi C8 RS6/RS7 CSF Intercoolers}

• Applications:
  • 2019+ Lamborghini Urus (incl. S, EVO, & Performante)
  • 2020+ Audi RS Q8
  • 2020+ Audi SQ8 – See CSF #8280/8280B
  • 2020+ Audi SQ7 – See CSF #8280/8280B
  • 2019+ Porsche Cayenne GTS / Turbo / Turbo S / Turbo GT
• OEM Part Numbers:
  • Lamborghini: 4M0145803AK (left) & 4M0145804AK (right)
  • Audi (RS Q8): 4M0145803BT (left) & 4M0145804BT (right)
  • Audi (SQ8/SQ7): 4M0145803BM (left) & 4M0145804BM (right)
  • Porsche (GTS / Turbo / Turbo S): PAB 145 803 B (left) & PAB 145 804 B (right)
  • Porsche (Turbo GT): PAB 145 803 E (left) & PAB 145 804 D (right)

The intercooler cores are spec'd out by CSF and custom built by PWR. Featuring two rows of rolled cooling tubes with inner fins, these cores make for the most efficient intercoolers available. Because of this, they are able to eliminate heat soak and lower IATs much more efficiently than traditional Bar & Plate or Tube & Fin designs. This gives us maximum performance for extended periods of time under demanding driving conditions and for vehicles with increased power levels through modifications and tuning.
